Use mouse to rotate MAXchair
MAX Chair – Patients are transported in this chair in a seated position inside the ambulance
Order number:
- 60-4500-001 MAX CHAIR
- 65-0409-001 MAX POWER
- 60-0251-008 MAX FASTENER
Wheels
The Chair is fitted with two large wheels with brakes at the rear and two swiveling castors below the foot rest.
Footrest
The footrest is used to support the legs and it is rotatable. The foot support is part of this chair.
Telescopic carrying handles
The MAX chair is fitted with telescopic carrying handles to aid in carrying the chair when necessary.
Back handles
Back handles are used to lift the Max chair to overcome larges obstacles.
Description
Specifications
Accessories
Support
Description
- Patients are transported in this chair in a seated position inside the ambulance
- Frame constructed with welded aluminium for a long life and a carry capacity of up to 250 kg
- Max Power is a ideal and cost effective solution of a removable Powertraxx with telescoping handle
- That can be easily attached or removed from the chair (to minimize the weight that needs to be carried by the operator)
- Red powder-coating finish prevents oxidation for clean hands and clothing
- Anatomically-shaped seat
- Easy to clean 100% Polyester, Vinyl cover can be disinfected
- Armrest kit with anti-slip plastic coating
- Two 125 mm front swivel wheels and two 150 mm rear fixed wheels with locks
- Telescoping carrying handles at front and rear ends
- Front telescoping handles adjustable in five positions (maximum extension of 340 mm)
- Folding footrest
- Optional MAX Power, IV Pole
Specifications
- Length 830 mm
- Width 595 mm
- Height 1225mm
- Weight 20 kg
- Load limit 250 kg
Accessories
MaxPower
Order number: 65-0409-001
a telescoping handle and an intelligent stair-track battery powered system that easily glides up and down stairs with loads up to 227 kg without the need to carry or lift (up to 20 flights of stairs per charge). The chair is easy to operate when climbing or descending stairs with intuitive, easy-to-use paddle-style controls to keep you in control.
Fastener
Order number: 60-0251-008
tested and compliant with EN 1789 Standards, stainless steel housing components, automatic locking when loading chair into fastener, manual release button (with mechanicla release)
IV Pole
Order number: 65-1500-031
This rugged and lightweight IV Pole offers an integrated height adjustment which allows operators to set their desired height for treatment
